The Swarovski ATX Modular Eyepiece can be combined with either the 65mm, 85mm or 95mm Modular Objectives.

SWAROVISION Technology

• Field Flattener Lens: Contrast right up to the image periphery, spot greater detail at the outer edge of the image
• HD Lenses: Maximum Contrast, provides more life-like high contrast images
• Extra Eye Relief: Large field of view for eyeglass wearers.
• Optimized coatings: SWARODUR, SWAROTOP, SWAROCLEAN

Optical Perfection-Combines a large field of view with a large zooming range (25-60x & 30-70x)

Ergonomics

• One handed operation: focusing and zooming ring are located next to each other which enables quick locating and zooming
• Large focusing wheel allows for easy and rapid focusing

Ingenious System-The objective section separates from the eyepiece section, is easy to transport and enables easy storage when separated.

Solutions for Photography And Digiscoping

• DCB II - For use with point and shoot and pancake lenses cameras
• Compatible with the eyepieces of the ATS/STS & ATM/STM (adapter sleeve and a locking ring needed)åÊ
• TLS APO - Developed as a complete system with the ATX/STX
• Connect D-SLR or mirrorless cameras
• Compatible with ATS/STS and ATM/STM (adapter sleeve and locking ring needed)



  Technical Data

  Length (in / mm)	6.7 / 170
  Weight (oz / g)	30.5 / 865
  Functional temperature	-13 F to +131 F (-25 C to +55 C)
  Storage temperature	-22 F to +158 F (-30 C to +70 C)
  Submersion tightness	13 ft (4m) water depth (inert gas filling)
