Swarovski BTX Eyepiece

Original price $3,699.00 - Original price $3,699.00
Original price
$3,699.00
$3,699.00 - $3,699.00
Current price $3,699.00

The BTX was a revolution in observation technology, and the results are dramatic. If you truly want to see it all, the BTX’s binocular capabilities make it unparalleled in both glassing efficiency and accuracy.

The BTX features an adjustable forehead rest, an angled ocular system, and the fact that both eyes can be used for viewing with maximum comfort over long periods

The BTX Modular uses the 95 mm, 85 mm, and 65 mm Objectives of the current SWAROVSKI OPTIK ATX/STX Modular system.

The 95 mm Objective Lens will be a fixed 35x, the 85 Objective Lens a fixed 30x, the 65 mm Objective Lens a fixed 30x.

Features SWAROVISION Technology Field Flattener and High Definition Lenses: Gives perfect edge-to-edge clarity, eliminates several kinds of distortion, brings out the highest color contrasts, and offers increased eye relief.

The interpupillary distance is adjustable, just like on a binocular. In the case of the BTX, the eyepieces operate simultaneously so they remain centered. No need to move away from the forehead rest while adjusting.

The black housing which incorporates the forehead rest can be removed for cleaning.

New Accessories

ME 1.7x magnification extender (Sold Separately)

This magnifier fits between the ocular and objective modules of the BTX/ATX/STX series. It increases the 30x magnification of the 65 mm and 85 mm objective modules to 50x and the 35x magnification of the 95 mm objective modules to 60x. If the ME 1.7x is used with the ATX/STX ocular and the 65 mm or 85 mm objectives, the maximum magnification is 100x. If the ME 1.7x is used with the ATX/STX ocular and the 95 mm objective the maximum magnification is 120x. BR balance rail (SOLD SEPARATELY) Designed to be compatible with the Arca-Swiss mounting system Two support points for complete balance and stability

Weight 3lb 2oz
Weight w/ 65mm Objective 4lb 13oz
Weight w/ 85mm Objective 5lb 9oz
Weight w/ 95mm Objective 6lb 1oz
Weight w/ 115mm Objective 7lb 12oz
Length 6.9 in
Length w/ 65mm Objective 15 in
Length w/ 85mm Objective 16.3 in
Length w/ 95mm Objective 18.5 in
Length w/ 115mm Objective 19 in
Magnification w/ 65mm and 85mm 30x
Magnification w/ 95mm and 115mm 35x
Field of View w/ 65mm and 85mm 112 ft
Field of View w/ 95mm and 115mm 96 ft
60 Days Money Back Guarantee Lifetime Limited Warranty
